High-speed Four-head Tracking Filling Machine

This High-speed Four-head Tracking Filling Machine is an advanced automated equipment designed by Taiyang for skin care products and daily necessities such as face cream, shampoo, laundry detergent, etc. This equipment adopts an integrated filling and capping design, uses a servo motor to drive the piston cylinder filling and the rotary wheel capping, and is equipped with a CIP cleaning system and bottle clamping function to ensure the high quality and stability of filling and capping. This Taiyang High-speed Four-head Tracking Filling Machine optimizes production efficiency while maintaining stability and precision. This filling machine is very suitable for the systematic production needs of medium and large enterprises and the production needs of multiple products.
Model:TY-1968

Send Inquiry

Product Description

This is Taiyang High-speed Four-head Tracking Filling Machine with excellent performance, which brings a new solution for modern efficient production.
One of Taiyang High-speed Four-head Tracking Filling Machine outstanding advantages is that it has four filling heads, which greatly improves production efficiency. The tracking function is even more unique. Taiyang High-speed Four-head Tracking Filling Machine can track the location and status of the product in real time to ensure the accuracy of filling. Even at high speed, the material can be accurately filled into the container to avoid waste and inaccurate filling. Multiple filling heads work simultaneously, which can complete the filling task of a large number of products in a short time to meet the needs of large-scale production. The Taiyang High-speed Four-head Tracking Filling Machine also has the advantages of easy operation and easy maintenance. The intelligent control system allows operators to easily adjust parameters to adapt to the filling of products of different specifications. At the same time, its sturdy and durable design ensures the long-term stable operation of the equipment and reduces maintenance costs.
Whether in the food, daily chemical, cosmetics and other industries, this Taiyang High-speed Four-head Tracking Filling Machine can play a huge role, and can form a more complete production line with equipment such as capping machines and labeling machines, providing strong support for enterprises to improve production efficiency, improve product quality and reduce production costs.


Technical Parameter

Model: TY-1968
Filing heads: 4 heads
Filling capacity: 100-2500ml/5000ml
Filling speed: 50-80 BPM
Filing type: Automatic tracking piston filling
Filling accuracy: ±0.5%
Air pressure: 0.5-0.8 MPa
Dimension: 6800x1100x2400mm
Weight: 1000KG
Power supply: 3KW,220V, 50Hz,
Material: SUS 304/316

Performance And Features

1.Suitable for different bottle shapes and products, like liquid soap, detergent, shampoo, hair conditioner etc.

2.Automatic PLC control system, easy setting parameters on HMI,easy to operate.

3.Intelligent recipe save function for different products,easy to change products

6.Servo filling system with higher filling accuracy, piston cylinder independent control, volume also can be adjusted separately

7.Equipped with twohead high speed capping system, torque adjustable, pump head can be positioned

8.Equipped with 300L product hopper with Sign glass window, CIP clean system and Material Level Controller

9.All contact parts adopt SUS316, other parts use SUS304


Application

Taiyang High-speed Four-head Tracking Filling Machine is widely used in different kinds of product filling, such as, shampoo, shower gel, hand cleaning gel,

laundry detergent and many other daily chemical products.At a viscosity of around 1000, the filling machine can achieve maximum performance

Product details

Adopt servo following filling method, with high filling accuracy.

Equipped with 300L visual large-capacity hopper.Four piston cylinders are independently controlled.Each filling nozzle can be controlled separately.

Double screw capping reduces capping time and ensures each cap is screwed tightly.

The chain conveyor belt is with large loading capacity,it can transport bottles faster and stably The guard rail for conveyor belt can be adjusted according to bottle diameter.
